Acoustic Movable Partition Wall with STC Rating 42-56dB and 304 Stainless Steel Rollers

Nombre De La Marca:	AE
Número De Modelo:	El AE85
Cuota De Producción:	10 metros cuadrados
Precio:	USD 80-100 Per Square Meter
Condiciones De Pago:	L/C, D/A, D/P, T/T, Western Union, Moneygram
Capacidad De Suministro:	1000 metros cuadrados por mes

Información detallada

Descripción del producto

Información detallada

Lugar de origen:

Guangdong, China

Certificación:

ISO9001 SGS

Nombre del producto:

Paredes movibles acústicas

Cumplimiento:

Sala de reunión, escuela

Espesor:

los 89cm

Clasificación STC:

Entre 42 y 56 dB

Acabado superficial:

Melamina, papel de pared, MDF, etc., puede ser personalizado

Dimensiones:

Personalización (altura: hasta 6 m, ancho por panel: hasta 1,2 m)

Detalles de empaquetado:

capa de espuma y cartón duro con estuche de madera contrachapada o paleta de acero

Resaltar:

STC Rating 42-56dB Movable Partition Wall

304 Stainless Steel Rollers Acoustic Movable Walls

6061-T6 Profile Sliding Folding Partitions

Descripción del producto

Acoustic Sliding Folding Partitions Movable Walls for Office Rooms & Banquet Halls

Our acoustic sliding movable wall partitions provide an efficient space separation solution for office rooms and banquet halls. Featuring a top-hung system that eliminates floor tracks, these partitions offer streamlined installation and operation. Constructed with a high-density aluminum frame, premium sound-insulating materials, and specialized rubber seals, they deliver exceptional soundproofing performance for conference rooms and multi-purpose spaces.

High-Quality Service Commitment

SGS and ILAC-MRA certified products ensuring reliable performance
German partition technology for global professional space solutions
Extended product lifespan with long-term performance stability
Quick follow-up and transparent quoting services
On-site inspection services for quality assurance
Punctual delivery to maintain project schedules

Premium Roller System Features

Dupont POM rollers for smooth operation
304 stainless steel construction with heavy-duty capabilities
Precision CNC machining with integrated safety features
Patented wheel design for effortless partition movement

Panel Specifications

100mm thickness for enhanced stability and sound insulation
Multiple acoustical and decorative finish options
Robust 6061-T6 profile with Q235 steel internal frame
Top and bottom jack lifting mechanisms (800N sealing power)
Magnetic seal with concave-convex profiles (40N/m attraction)

Technical Specifications

GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSIONAL SPACE SOLUTIONS

Series	Element thickness (mm)	Element width* (min/max)	Clear height* (min/max)	Construction	Panel fixing	Element interconnection
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips

Technology: Weighted sound reduction value (Rw) determined per GB/T19889.3-2005: 52/56 dB

Locking System: Positive and frictional locking with convex-concave profile form, magnetic strip attraction force of 40 N/m

* Larger widths available upon request. Final dimensions subject to Design Department confirmation.
