Customizable Movable Partition Wall with 68CM Thickness and 800N Sealing Power Operable Wall System

Nombre De La Marca:	AE
Número De Modelo:	El AE65
Cuota De Producción:	10 metros cuadrados
Precio:	USD 79-108 per square meter
Condiciones De Pago:	T/T, L/C, Unión Occidental
Capacidad De Suministro:	1000 metros cuadrados por mes

Información detallada

Descripción del producto

Información detallada

Lugar de origen:

Cantón, China

Certificación:

ISO9001 SGS CANS

Serie:

AE65 Pared divisoria móvil

Opción de finalización:

Materiales suministrados por el cliente

Aplicación:

Restaurante, sala de reuniones

Espesor:

los 68cm

Clasificación STC:

Entre 42 y 56 dB

Dimensiones:

Personalización (Alta: hasta 4,5 m, ancho por panel: hasta 1,2 m)

Nombre:

Pared divisoria móvil

Detalles de empaquetado:

capa de espuma y cartón duro con estuche de madera contrachapada o paleta de acero

Resaltar:

68CM Thickness Movable Partition Wall

800N Sealing Power Operable Wall System

40N/m Magnetic Attraction Room Divider

Descripción del producto

Customizable Movable Partition Wall Office Operable Wall Systems

AE operable partitions are a series of panels suspended from tracks with high quality, functionality and variability for room-dividing and multifunctional layout configuration.

Key Features

German Partition Technology Global Professional Space Solutions
Highly competitive prices
Good quality control
Smooth communication
State-of-art technology products
Effective OEM&ODM service

Roller Options & Features

Dupont POM roller
304 stainless steel heavy duty roller with safety device & CNC machining
Unique and patented wheel surface and shape for easy operation

Panel Options & Features

Thickness: 68mm, 89mm & 105mm options
Wide variety of acoustical and decorative finishes available
6061-T6 profile with Q235 steel frame for superior durability
Top & bottom jack lifting mechanism seal with 800N power
Magnetic seal in concave & convex profile with 40N/m magnetic attraction

Technical Specifications

Series	Element Thickness (mm)	Element Width (mm)*	Clear Height (mm)*	Construction	Panel Fixing	Element Interconnection
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
