Acoustic Movable Partition Wall with STC Rating 42-56dB and 105CM Thickness for Conference Rooms

Nombre De La Marca:	AE
Número De Modelo:	Serie 100
Cuota De Producción:	10 metros cuadrados
Precio:	USD 90-135 per square meter
Condiciones De Pago:	LC, T/T, Unión Occidental
Capacidad De Suministro:	1000 metros cuadrados por mes

Información detallada

Descripción del producto

Información detallada

Lugar de origen:

Cantón, China

Certificación:

ISO9001 SGS CANS

Modelo:

Pared divisoria móvil

Tablero base:

Materiales suministrados por el cliente

Aplicación:

Salón de banquetes, sala de conferencias

Espesor:

105 cm

Clasificación STC:

Entre 42 y 56 dB

Dimensiones:

Personalización (Alta: hasta 12M, ancho por panel: hasta 1.2M)

Nombre:

Pared divisoria móvil

Detalles de empaquetado:

capa de espuma y cartón duro con estuche de madera contrachapada o paleta de acero

Resaltar:

STC Rating 42-56dB Movable Partition Wall

105CM Thickness Movable Partition Wall

Customizable Dimensions Movable Partition Wall

Descripción del producto

Acoustic Conference Room Movable Partition Wall with Passageway Door

Intelligent solutions for flexible space utilization. Our sound-insulated or transparent movable partition walls enable efficient space configuration for virtually any application.

Key Advantages

Extensive experience with demanding commercial projects
Reliable delivery time management for large orders
Dedicated R&D team for custom product development
SGS & ILAC-MRA certified product performance
24-hour response to all product and pricing inquiries
Fluent English-speaking support staff
Custom manufacturing to your specifications

Roller System Features

Dupont POM rollers for smooth operation
304 stainless steel heavy-duty rollers with safety mechanisms
Patented wheel design for effortless partition movement

Technical Specifications

Series	Element Thickness (mm)	Element Width (mm)*	Clear Height (mm)*	Construction	Panel Fixing	Vertical Profile Design
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Magnetic strip with sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Magnetic strip with sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Magnetic strip with sealing lips

* Larger dimensions available upon request. Final specifications subject to engineering review.
** Sound insulation performance: Weighted sound reduction value (Rw) 52-56 dB (GB/T19889.3-2005)
*** Vertical connection system: Convex-concave profile with 40 N/m magnetic attraction force
