Customizable Movable Partition Wall with 89CM Thickness and Up to 6M Height Sliding Folding Partition

Nombre De La Marca:	AE
Número De Modelo:	El AE85
Cuota De Producción:	10 metros cuadrados
Precio:	USD 80-100 per square meter
Condiciones De Pago:	T/T, L/C, Unión Occidental
Capacidad De Suministro:	1000 metros cuadrados por mes

Información detallada

Descripción del producto

Información detallada

Lugar de origen:

Cantón, China

Certificación:

ISO9001 SGS CANS

Producto:

Pared divisoria móvil

Material de los paneles:

Materiales suministrados por el cliente

Cumplimiento:

Edificio de oficinas, escuela, hospital

Espesor:

los 89cm

Clasificación STC:

Entre 42 y 56 dB

Dimensiones:

Personalización (altura: hasta 6 m, ancho por panel: hasta 1,2 m)

Nombre:

Pared divisoria móvil

Detalles de empaquetado:

capa de espuma y cartón duro con estuche de madera contrachapada o paleta de acero

Resaltar:

89CM Thickness Movable Partition Wall

Up to 6M Height Sliding Folding Partition

Up to 1.2M Width per Panel Operable Wall Panel

Descripción del producto

Customization Movable Partition Wall - Sliding Folding Partitions

Our movable partition walls consist of multiple panels suspended from tracks, offering flexible and effective space management. These partitions are operated manually and require no special tools or equipment. The only tool needed is the operating handle, which locks and adjusts the mechanical seals at both the top and bottom, ensuring a precise acoustic seal when the panels are closed.

Our acoustically rated movable partition walls come in various configurations, including paired, individual (omnidirectional), and continuously articulated (train) options, catering to diverse spatial and acoustic needs.

Key Advantages

Extensive experience collaborating with major clients
Flexible control over order delivery timelines
Dedicated design team for new product development and solutions
Product performance certified by SGS and ILAC-MRA
Incorporates German partition technology for professional global space solutions
Extends service life of professional products

Roller Options & Features

High-quality Dupont POM rollers
Robust 304 stainless steel rollers for heavy-duty use with safety devices and CNC machining
Exclusive patented wheel surface and shape for enhanced system usability

Panel Options & Features

89mm thickness for enhanced stability and sound insulation
Diverse range of acoustical and decorative finishes
Robust 6061-T6 profile with Q235 steel frame for exceptional durability
Top and bottom jack lifting mechanisms with 800N sealing power
Magnetic seal with concave/convex profiles providing 40N/m magnetic attraction

Technical Specifications

GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSIONAL SPACE SOLUTIONS

Series	Element thickness (mm)	Element width* (min/max mm)	Clear height* (min/max mm)	Framed construction	Panel fixing	Element interconnection
AE65	68	600/1,250	2,000/4,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE85	89	600/1,250	2,000/5,500	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips
AE100	105	600/1,250	2,000/18,000	Aluminium-steel	Freely oscillating	Aluminium profile with magnetic strip and sealing lips

Technology: Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB): 52/56
Positive and frictional locking: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m
* Larger widths possible on application. Provisional details regarding the element heights/element widths indicated can only be confirmed following consultation with the Design Department.
** Depending on the sound insulation/weight
